Philips M4735A HeartStart XL AED/monitor is a new portable AED device from Philips with both manual and AED modes. It also supports SMART Biphasic waveform, ECG monitoring, synchronized cardioversion and optional non-invasive pacing and SpO2.
The HeartStart XL defibrillator/monitor provides both manual and AED operation for advanced and basic life support. It features Philips' patented SMART biphasic waveform, ECG monitoring, synchronized cardioversion, optional non‑invasive pacing and SpO₂ monitoring, and a built‑in 50 mm strip‑chart printer.
The device records patient summaries, stores data on an internal memory card, and supports data download via a data card. It includes a sealed‑lead‑acid battery, AC power integration, and a range of accessories such as external paddles, cables, and a battery charger kit.
| Dimensions (H × W × L) | 19.0 cm × 37.6 cm × 34.6 cm |
|---|---|
| Weight (including battery and paper) | 6.0 kg |
| Maximum charge time (battery) | < 3 seconds to 200 J |
| Battery type | 2 Ah, 12 V sealed lead‑acid |
| ECG lead options | 1‑lead, 3‑lead, 5‑lead configurations |
It charges to the highest energy level in less than 3 seconds when the battery is fully charged.
It uses a 2 Ah, 12 V rechargeable sealed lead‑acid battery.
Yes, it can be operated using only AC power when no battery is installed.
AED mode provides ECG monitoring, SpO₂ monitoring, voice prompts, and text messages while delivering shocks.
