The PM 6303 RCL meter is a handheld instrument for measuring resistance, capacitance and inductance with auto‑function and auto‑ranging. It displays the measured value, unit and an equivalent‑circuit symbol on a 4‑digit LCD, updating at about two measurements per second.
The manual includes safety guidelines, detailed specifications, measurement ranges, error codes and special user instructions for handling lossy components, bias modes, and high‑ohmic measurements. It is intended for trained personnel in laboratories, service workshops or educational settings.
| Display digits | 4 digits |
|---|---|
| Measurement update rate | approx. 2 measurements per second |
| Quality factor range | 0.002 – 500 |
Only trained and qualified personnel may operate, maintain or repair the instrument.
