This file is a service manual for the coffee maker, including the use instructions, technical information, schematic diagrams, repair methods and other information
This service manual provides detailed instructions for repairing the Philips Senseo HD7820/70 coffee maker. It includes safety notes, technical specifications, and step‑by‑step procedures for disassembly, re‑assembly, and component replacement.
Key sections cover volume adjustment, boiler flag reset, a complete parts list with reference numbers, and exploded view diagrams to aid technicians in diagnosing and fixing the appliance.
| Water tank capacity | 1200 cc |
|---|
Remove Screw A, then insert a screwdriver into the snap‑lock positions and gently pull the back cover away from the appliance.
Press the 1‑ and 2‑cup buttons simultaneously while the appliance is plugged in; the LED will blink and you can fine‑tune the volume by pressing the desired cup button.
