Performance parameters of 7500A series accelerometers, including input range, frequency range, sensitivity, output noise, maximum mechanical shock, etc.
The REV E 7500A series accelerometer provides a range of input options from ±2 g to ±400 g, with frequency responses up to 2500 Hz and sensitivities as high as 1000 mV/g. Detailed performance tables cover bias errors, temperature shifts, non‑linearity, and power supply rejection for each model variant.
Physical characteristics feature a titanium‑alloy case measuring 1.00 in × 1.00 in × 0.33 in, a mass of 13 g, and hermetic sealing. The device operates from 9 V to 32 VDC, draws 12–14 mA, and is rated for a maximum mechanical shock of 5000 gpk. Supplied accessories include mounting screws for secure installation.
| Operating Voltage | 9‑32 VDC |
|---|---|
| Case Length | 1.00 inch |
| Mass | 13 grams |
The accelerometer operates from 9 V to 32 VDC.
The case is made of titanium alloy.
The device can withstand up to 5000 gpk shock.
Mounting screws (4‑40 × 0.5 in) are included.
