This document describes the features and characteristics of the BZX84 series voltage regulator diodes, including maximum power dissipation, three tolerance series, working voltage range, and maximum non-repetitive peak reverse power dissipation.
The Philips BZX84 series consists of low‑power voltage regulator diodes offered in SOT‑23 plastic SMD packages. The series includes 37 types with nominal working voltages from 2.4 V to 75 V and three tolerance options (+1 %, +2 %, approx. +5 %).
The document provides electrical and thermal specifications, marking codes, and graphical data such as forward voltage curves and peak reverse‑power limits. It also lists storage and junction temperature ranges and includes contact information for Philips Semiconductors.
