74AHC1G08/74AHCT1G08 is a high-speed Si-gate CMOS device, implementing 2-input AND logic
The Philips 74AHC1G08 and 74AHCT1G08 are high‑speed Si‑gate CMOS 2‑input AND gates. The data sheet provides electrical characteristics, pin configuration, recommended operating conditions and package information.
Key features include symmetrical output impedance, high noise immunity, ESD protection, low power dissipation and a very small 5‑pin package. The document also covers AC and DC characteristics, soldering guidelines and worldwide contact details for Philips Semiconductors.
| Supply voltage (VCC) range | 2.0 V to 5.5 V |
|---|
The devices are rated for –40 °C to +85 °C.
