The GA-H67MA-UD2H motherboard is compatible with Intel® Core™ i7 processors, Intel® Core™ i5 processors, Intel® Core™ i3 processors, Intel® Pentium® processors, and Intel® Celeron® processors. It features various functions and components, including dual-channel memory technology, integrated peripherals, and power management setup.
This manual covers everything needed to install and configure the GA-H67MA-UD2H motherboard, including hardware installation, CPU and memory setup, and detailed product specifications. It also explains the layout of the board, connector functions, and optional accessories.
Additional sections describe BIOS settings, driver installation, unique Gigabyte features such as Q-Flash and Xpress Recovery, and provide appendices with troubleshooting, warranty information, and service contacts. This manual is written in Chinese.
| CPU Socket | LGA1155, supports Intel Core i7/i5/i3, Pentium, Celeron |
|---|---|
| Memory Slots | 4 DDR3 DIMM slots, up to 16 GB, DDR3 1333/1066/800 MHz, dual‑channel |
| Network | Realtek RTL8111E 10/100/1000 Mbit Ethernet |
It has four DDR3 DIMM slots that can support up to 16 GB of memory.
Enter the BIOS, launch the Q‑Flash utility, select the BIOS file and follow the on‑screen prompts to perform a quick update.
The board supports LGA1155 processors including Intel Core i7, i5, i3, Pentium and Celeron models.
