The BTS7710GP data sheet introduces the features of the Quad D-MOS switch driver. The product is optimized for DC motor management applications. Its typical RDS ON is 70 mτ, the maximum peak current is 15 A, and the quiescent current is 5 ←A. The product has load short circuit protection, overtemperature shut down, internal clamp diodes, external current detection, etc.
The BTS 7710 GP is a quad D‑MOS switch driver from Infineon's TrilithIC family, offering a configurable bridge or quad‑switch layout optimized for DC motor management. It features low on‑resistance, high peak current capability, very low quiescent current, built‑in protection functions, and supports PWM frequencies up to 50 kHz.
The datasheet includes sections on features, pin configuration and definitions, functional block diagram, circuit description, absolute maximum ratings, operating range, and package outlines, providing all necessary information for designers to integrate the device into automotive or industrial applications.
| Maximum peak current | 15 A (typical @ 25 °C) |
|---|---|
| Quiescent current | 5 pA (typical @ 25 °C) |
| Operating voltage range | Up to 40 V |
| PWM frequency | Up to 50 kHz |
| High‑side drain current (absolute max) | 10 A |
| Low‑side continuous drain current (absolute max) | 12 A |
| Low‑side pulsed drain current (absolute max) | 20 A |
| Junction temperature range | -40 °C to 150 °C |
The device can handle a typical peak current of 15 A at 25 °C.
It supports PWM frequencies up to 50 kHz.
