max4906ef is a single-supply, low on-resistance, low on-capacitance analog switch from texas instruments, suitable for usb2.0 high-speed applications
The MAX4906EF is an electrostatic‑discharge‑protected analog switch designed for USB 2.0 high‑speed (480 Mbps) applications. It features two SPDT switches, operates from a single 2.7 V to 3.6 V supply, and includes a charge‑pump standby mode with a quiescent current of 3 µA.
The device is offered in a 2 mm × 2 mm 10‑lead UDFN package, supports operation from –40 °C to +85 °C, and provides +15 kV HBM ESD protection on the COM pin. Detailed electrical characteristics, pin functions, and package dimensions are provided in the datasheet.
| ESD protection (COM pin) | +15 kV (Human Body Model) |
|---|---|
| Supply voltage range | 2.7 V to 3.6 V |
| Bandwidth (‑3 dB) | 500 MHz (typ) |
| Operating temperature range | -40 °C to +85 °C |
| Package type | 10‑lead 2 mm × 2 mm UDFN |
| Number of channels | 2 SPDT switches |
The COM pin is protected against +15 kV human‑body‑model ESD.
It operates from a single supply voltage of 2.7 V to 3.6 V.
It is offered in a 10‑lead 2 mm × 2 mm UDFN package.
