MAX4927 is a high-performance, low-power, 4-pair bidirectional switch that meets the needs of Gigabit Ethernet (10/100/1000) Base-T switching as well as LVDS and LVPECL switching.
The MAX4927 is a high‑speed analog switch designed for 1000 Base‑T Ethernet, LVDS, LVPECL and other low‑voltage differential signals. It offers up to +15 kV ESD protection, ultra‑low on‑resistance and capacitance, and built‑in LED switches for docking‑station applications.
The device is supplied in a space‑saving 56‑pin TQFN package (5 mm × 11 mm) and operates from –40 °C to +85 °C. Detailed electrical characteristics, pin descriptions, and layout recommendations are provided for designers.
| ESD protection (Air‑Gap) | +15 kV |
|---|---|
| ESD protection (Contact) | +8 kV |
| ESD protection (Human Body Model) | +15 kV |
| On‑Capacitance (Con) | 8 pF typ |
| -3 dB Bandwidth | 650 MHz |
| Package | 56‑Pin TQFN, 5 mm × 11 mm |
| Operating Temperature Range | -40 °C to +85 °C |
The MAX4927 offers +15 kV air‑gap discharge, +8 kV contact discharge, and +15 kV human‑body model protection.
It is supplied in a 56‑pin TQFN package measuring 5 mm × 11 mm.
The device operates from –40 °C to +85 °C.
