This manual covers safety precautions, proper installation, and connection of power, water, and drain hoses for the Samsung XQB50-20 and XQB52-20 front‑load washing machines. It explains how to level the unit, attach the inlet and outlet pipes, and secure the acoustic panel.
The guide also details the control panel functions, washing programs (standard, wool, quick, and reservation), manual settings, cleaning methods, troubleshooting tips, and technical specifications such as power consumption, capacity, dimensions, and spin speeds. This manual is written in Chinese.
| Rated Power Consumption | 330 W |
|---|---|
| Washing Capacity | 5.0 kg (XQB50-20) / 5.2 kg (XQB52-20) |
| Dimensions (W×D×H) | 520 mm × 530 mm × 850 mm |
| Product Weight | 30 kg |
| Standard Water Consumption | 50 L per cycle |
| Water Pressure Range | 0.03 MPa – 1 MPa |
| Spin Speed (Wash) | 145 rpm |
| Spin Speed (Drain) | 7680 rpm |
Hold the plug firmly and pull the plug out of the socket; do not pull on the cord itself and avoid placing heavy objects on the cord.
Insert the drain pipe into the drain hole until the base, secure it with the connecting ring, adjust its length and bend as needed, and ensure no leaks.
Press the reservation button once for each hour; each press adds one hour, allowing a range from 3 to 18 hours in one‑hour increments.
Do not exceed 30 °C when washing wool items.
