TLP2105 is a photocoupler from Toshiba, which features high gain, high-speed photodetectors and totem-pole output stage. It utilizes GaAℓAs light emitting diodes and integrated high gain, high-speed photodetectors. It provides noninverting logic output and has an internal Faraday shield that provides a guaranteed common-mode transient immunity of ±10 kV/μs.
The Toshiba TLP2105 is a GaAs light‑emitting diode and high‑gain photodetector optocoupler housed in an 8‑pin SO package. It provides a non‑inverting logic output with a totem‑pole stage, isolation voltage up to 2500 Vrms and common‑mode transient immunity of +10 kV/µs.
The document lists absolute maximum ratings, electrical characteristics, switching performance, and detailed tape‑and‑reel packaging specifications, along with handling, storage and usage restrictions for reliable integration in electronic designs.
| Supply Voltage | 4.5 V – 20 V |
|---|---|
| Isolation Voltage (AC, 1 min) | 2500 Vrms |
| Common‑Mode Transient Immunity | +10 kV/µs |
| Input Threshold Current | 1.6 mA (max) |
The device operates with a supply voltage between 4.5 V and 20 V.
It is rated for 2500 Vrms isolation voltage (AC, 1 minute).
The coupler offers a common‑mode transient immunity of +10 kV/µs.
