This document introduces the TC7SHU04FE CMOS digital integrated circuit from Dinghao, which features super high-speed operation, low power dissipation, high noise immunity, and wide operation voltage range.
The TC7SHU04FE is a CMOS digital integrated circuit inverter with high‑speed operation (typical propagation delay 3.5 ns) and low power dissipation. It operates from a supply voltage of 2 V to 5.5 V and is tolerant to input voltages up to 7 V.
The datasheet provides absolute maximum ratings, electrical characteristics, package dimensions (SON5‑P‑0.50), and usage restrictions. It also includes a logic diagram, truth table, and notes on reliability and handling for designers.
| Supply voltage range (Voc) | 2 V ~ 5.5 V |
|---|---|
| Input voltage range (VIN) | 0 V ~ 5.5 V |
| Output voltage range (Vout) | 0 V ~ Voc |
| Operating temperature | -40 °C ~ 85 °C |
| Power dissipation (Pp) | 150 mW |
| Typical propagation delay (tPHL) | 3.5 ns |
| Input capacitance (CIN) | 5 pF ~ 10 pF |
| Package type | SON5‑P‑0.50 |
| Weight | 0.003 g (typ.) |
It operates from 2 V to 5.5 V supply voltage.
The device can dissipate up to 150 mW.
The IC is rated for temperatures from –40 °C to +85 °C.
It is supplied in a SON5‑P‑0.50 surface‑mount package.
