EL7156 is a high performance pin driver with three-state from Intersil, which is suitable for many ATE and level-shifting applications.
The EL7156 is a high‑performance pin driver with three‑state capability, designed for ATE, level‑shifting, and IGBT driver applications. It offers a 3.5 A peak drive current and operates from 4.5 V to 16.5 V, making it suitable for high‑capacitance loads.
The document includes absolute maximum ratings, detailed electrical specifications, pinout diagrams, typical performance curves, and package information for both 8‑lead SOIC and PDIP versions. Application notes cover power‑supply bypassing, thermal calculations, and recommended PCB layout guidelines.
| Peak Output Current | 3.5 A |
|---|---|
| Supply Voltage Range | 4.5 V to 16.5 V |
| Input Capacitance | 3.5 pF |
| ON‑Resistance (typical) | 3.5 Ω |
The EL7156 can source up to 3.5 A of peak output current.
It operates from 4.5 V up to 16.5 V.
The typical input capacitance is 3.5 pF.
