The ISL89410, ISL89411, ISL89412 are high speed dual channel power MOSFET drivers with very high switching speed, low input capacitance, low output impedance, high noise immunity, large driving current, etc., which can be used in clock drive, CCD drive, ultrasonic drive and other fields.
The ISL89412 series are high‑speed, dual‑channel power MOSFET drivers offering up to 2 A peak output current into highly capacitive loads. Their proprietary “Turbo‑Driver” circuit provides fast rise/fall times and reduced clock skew, while maintaining low supply current.
The devices operate from 4.5 V to 18 V, support a wide temperature range, and are available in both PDIP and SOIC packages, including RoHS‑compliant Pb‑free options. Application notes cover layout recommendations for minimizing inductance and optimizing gate drive performance.
| Peak Output Current | 2 A |
|---|---|
| Operating Voltage Range (V+) | 4.5 V to 18 V |
| Low Supply Current (Typical) | 2.5 mA to 5.0 mA (high inputs) |
| Rise Time (500 pF load) | 75 ns |
The driver can deliver up to 2 A peak current into highly capacitive loads.
The recommended operating V+ range is 4.5 V to 18 V.
Typical high‑input supply current is between 2.5 mA and 5.0 mA.
