AD8180/AD8182 are high performance, low power 2 to 1 switching multiplexers with 10ns switching time and 750MHz bandwidth.
The AD8180 and AD8182 are high‑speed video multiplexers designed for pixel‑switching, LCD/Plasma displays and video routers. They offer fully buffered inputs and outputs, 10 ns channel switching, >750 MHz small‑signal bandwidth, low power (3.8 mA or 6.8 mA per active channel) and excellent crosstalk and isolation performance.
The devices operate from a +5 V supply (range +4 V to +6 V) and are available in 8‑lead DIP, 14‑lead DIP and SOIC packages. The datasheet includes detailed specifications, functional block diagrams, theory of operation, layout guidelines, ordering information and evaluation‑board details.
| Power‑Supply Operating Range | +4 V to +6 V |
|---|---|
| Quiescent Current (All Channels ON) | 3.8 mA (AD8180) / 6.8 mA (AD8182) |
| Off‑Isolation | -90 dB at 5 MHz |
They operate from a +5 V supply with an allowed range of +4 V to +6 V.
The off‑isolation is specified as –90 dB at 5 MHz.
