AD8184 is a 4-to-1 video multiplexer with a bandwidth of 700 MHz and a current consumption of less than 4.5 mA, providing up to 95 dB of isolation and 115 dB of crosstalk.
The AD8184 video multiplexer provides fast 10 ns switching and a wide >700 MHz bandwidth while consuming only about 4.4 mA at 5 V. It features fully buffered inputs and outputs, low‑glitch operation, high OFF isolation (‑115 dB) and excellent crosstalk performance (‑95 dB at 5 MHz). The device is offered in 14‑lead PDIP and SOIC packages and includes a fast disable function for cascading multiple muxes.
The datasheet lists detailed electrical specifications, absolute‑maximum ratings, layout guidelines, and example application circuits. Performance curves illustrate bandwidth, gain flatness, transient response, and power‑supply rejection. Ordering information and mechanical dimensions are also provided.
| Channel Switching Time (50% to 90% output settling) | 10 ns |
|---|---|
| Slew Rate | 600‑750 V/µs |
| Operating Voltage Range | +4 V to +6 V |
The AD8184 switches from 50 % to 90 % of the output in about 10 ns.
The device operates from a supply voltage of +4 V to +6 V.
