The ADG1404 is a complementary metal-oxide semiconductor (CMOS) analog multiplexer, comprising four single channels designed on an iCMOS process. It features 1.5Ω on resistance, 0.3Ω on-resistance flatness, and 0.1Ω on-resistance match between channels.
The ADG1404 is a complementary CMOS analog multiplexer with four single‑ended channels designed for high‑performance, low‑power applications such as automatic test equipment, data acquisition, and battery‑powered instruments. It operates with ±15 V, ±12 V, or ±5 V supplies and features rail‑to‑rail operation, low on‑resistance, and break‑before‑make switching.
Key specifications include a typical on‑resistance of 1.5 Ω, continuous current capability up to 400 mA, and input voltage ranges from 0.8 V to 2.0 V. The device is offered in 14‑lead TSSOP and 16‑lead LFCSP packages and complies with JEDEC standards.
| Typical On‑Resistance (Ron) | 1.5 Ω |
|---|---|
| Continuous Current | Up to 400 mA |
| Supply Voltage Options | +15 V, +12 V, +5 V |
| Input Low Voltage (VINL) | 0.8 V max |
| Number of Channels | 4 single‑ended channels |
The typical on‑resistance is 1.5 Ω.
It can handle up to 400 mA of continuous current.
The device is fully specified for +15 V, +12 V, and +5 V supplies.
