This document provides information about the VSX II™ Electronic Crossover 2 product, including features, instructions for use, and safety warnings.
This manual explains how to safely install and operate the Peavey VSX II electronic crossover. It begins with safety warnings about dangerous voltage, moisture exposure, and proper grounding, then guides the user through mounting, power connection, and initial setup.
The guide details each control – gain knobs, crossover frequency selector, polarity switches, and LED indicators – and describes the balanced XLR, 1/4" and Euro connectors for inputs and outputs. It also covers the filter characteristics, gain range, and recommended procedures for configuring stereo or mono operation.
| Crossover frequency range | 60 Hz – 6 kHz |
|---|---|
| Filter slope | 24 dB per octave |
| Gain control range | -20 dB to +20 dB (unity at center) |
| Low‑pass filter corner frequency | 40 Hz (24 dB/octave roll‑off) |
| Input/Output connector types | XLR, 1/4" (TRS), 3‑pin Euro (balanced) |
| Power connector | Standard IEC power connector |
Connect it to a grounded outlet using the IEC power connector, never break off the ground pin, and keep the unit away from rain or moisture.
The crossover frequency can be set between 60 Hz and 6 kHz using the recessed rotary knob.
Yes, inserting a mono TS 1/4" jack makes that channel unbalanced; otherwise all connections are balanced.
