This manual begins with safety warnings that alert the user to dangerous voltages inside the unit and advise against opening the enclosure, exposing the device to moisture, or attempting user repairs. All servicing should be performed by qualified Peavey service personnel.
The guide then describes the XD 2/3/4’s features, front‑panel controls, input and output connectors, and detailed setup procedures. It includes specifications such as gain range, crossover frequency ranges, power requirements, and distortion limits, followed by a warranty statement for Peavey products.
| 40 Hz Roll‑off Switch attenuation | -3 dB @ 40 Hz, 12 dB/octave |
|---|---|
| Channel Gain Control range | ±10 dB |
| Low Frequency Level Control range | - to +6 dB |
| Mid Frequency Level Control range | - to +6 dB |
| High Frequency Level Control range | - to +6 dB |
| Low‑to‑Mid Crossover range | 50 Hz–500 Hz or 500 Hz–5 kHz |
| Mid‑to‑High Crossover range | 800 Hz–8.2 kHz |
| Maximum Input Level | +18 dBV, 8 V RMS |
| Maximum Output Level | +18 dBV, 8 V RMS |
| Input Impedance | 20 kΩ balanced, 10 kΩ unbalanced |
It provides a 12 dB per octave roll‑off at 40 Hz to reduce subsonic rumble and protect sub‑woofer speakers from operating below their cutoff frequency.
