RQ 200 Six Channel Mini Console ™ is a six-channel mixing console from Behringer
The RQ200 is a compact six‑channel mini console designed for sound reinforcement and recording applications. It offers two mono and four stereo input channels, a low‑noise design, phantom power, and multiple output options (balanced/unbalanced RCA, 1/4" TRS, and 3.5 mm). The guide details each channel’s functions, master section controls, and recommended wiring practices.
Key sections include Channel Functions, Master Section, Power (AC adapter or battery operation), Application Notes, and detailed Input/Output specifications. Safety warnings and warranty information are also provided.
| Power Requirements (AC) | 16.5 VAC, 1 A |
|---|---|
| Phantom Power (AC) | 22 VDC |
| Dimensions (H × W × D) | 3" × 13.875" × 10" |
| Weight | 5.5 lb (2.5 kg) |
It has six input channels: two mono channels and four stereo channels, providing a total of 14 inputs at mixdown.
Plugging into the 1/4" headphone output automatically disconnects the 3.5 mm headphone output, allowing you to switch between headphones and powered speakers.
