This file introduces important information in the operating guide, including operating and maintenance instructions, and the meaning of electrical safety symbols
This Operating Guide warns of dangerous uninsulated voltages inside the amplifier and instructs users to avoid opening the unit, recommending that all servicing be performed by qualified personnel. Safety symbols and multilingual cautions are presented on the first pages.
The guide details every front‑panel and rear‑panel control, including the master volume, channel‑select switch, active EQ (Bottom, Body, Hair), effects loop, cabinet‑impedance selector, and remote footswitch connection. It also includes a block diagram of the signal path, power‑amp and pre‑amp specifications, and warranty information.
| Power Output | 120 W RMS into 16, 8, or 4 Ω |
|---|---|
| Power Consumption | Domestic: 400 W, 50/60 Hz, 120 VAC |
| Power‑Amp Tubes | Four 6L6GCs with 12AX7 driver |
| Pre‑Amp Tubes | Three 12AX7s |
| Frequency Response | ±3 dB from 50 Hz to 20 kHz |
| Dimensions | 11.0" H × 26.5" W × 11.0" D (279 mm × 673 mm × 279 mm) |
| Weight | 52 lb (23.6 kg) |
| Clean Channel Nominal Input Level | -20 dBV (100 mV RMS) |
Connect the footswitch to the 7‑pin DIN Remote Switch connector before powering up the amp.
