This manual begins with important safety instructions, warning symbols, and guidelines for proper power connection, grounding, and environmental precautions. It also outlines the required speaker impedance and cautions against exposure to moisture or improper voltage.
The remainder of the guide details the rear and front panel features, including the power switch, AC input, fuse, ground polarity switch, external speaker jack, input select, pre‑gain, EQ controls, DDT speaker‑protection system, headphone jack, and remote footswitch. Wiring diagrams, control functions, and troubleshooting tips are provided to help users achieve optimal tone and protect the amplifier.
| Minimum speaker impedance (TNT 115) | 4 Ω |
|---|---|
| Internal speaker impedance (TNT 115) | 4 Ω |
| Internal speaker impedance (TKO 115) | 8 Ω |
The external speaker cabinet must have an impedance of at least 4 Ω for the TNT 115.
Set the DDT Speaker Protection System Switch to the “DEFEAT” (IN) position.
The recommended footswitch is Peavey model #00051000.
