This document describes the features and characteristics of the 250 MHz Dual DCL ADATE205 Rev. A product, including driver, comparator, and active load functions, 250 MHz toggle rate, dynamic clamps, operating voltage range of -1.5 V to +6.5 V, output voltage swing of 200 mV to 8 V, four range adjustable slew rate, true/complement data mode bit, 100-lead thin quad flat package, etc.
The ADATE205 is a single‑chip dual driver‑comparator‑active‑load (DCL) solution designed for automatic test equipment, semiconductor test systems, board test systems, and instrumentation. It provides driver, comparator, and active‑load functions with programmable slew rates and an inhibit mode, all in a 100‑lead thin quad flat package with exposed pad.
Key specifications include an operating voltage range of –1.5 V to +6.5 V, a 250 MHz toggle rate, low leakage (<10 nA) in High‑Z mode, and typical power dissipation of about 3 W when the load is enabled. The datasheet also provides detailed electrical characteristics, absolute maximum ratings, and ordering information.
| Operating voltage range | -1.5 V to +6.5 V |
|---|---|
| Toggle rate | 250 MHz |
| Output voltage swing | 200 mV to 8 V |
| Package | 100‑lead thin quad flat package, exposed pad |
| Power dissipation (load off) | 1.15 W |
| Typical total power dissipation (load enabled at 20 mA) | 3 W |
The ADATE205 operates from –1.5 V to +6.5 V.
The device supports a 250 MHz toggle rate.
It is supplied in a 100‑lead thin quad flat package with an exposed pad.
Typical total power dissipation is about 3 W with the load enabled at 20 mA.
