The AD5360/AD5361 16-Channel, 16/14-Bit, Serial Input, Voltage-Output DAC is a 16-channel, 16/14-bit, serial input, voltage-output DAC with multiple output voltage ranges and features for use in instrumentation, industrial control systems, level setting in automatic test equipment (ATE), and variable optical attenuators (VOA) applications.
The AD5360 and AD5361 are 16‑channel voltage‑output DACs offered in 52‑lead LQFP and 56‑lead LFCSP packages. They provide buffered outputs with a nominal range of –10 V to +10 V, programmable gain and offset per channel, and a high‑speed 4‑wire serial interface compatible with SPI, QSPI, Microwire, and DSP standards.
The document includes detailed specifications such as resolution, accuracy, supply voltage ranges, timing parameters, pin configurations, and calibration procedures, as well as application notes for instrumentation, industrial control, and test equipment.
| Resolution | 16 bits (AD5360) / 14 bits (AD5361) |
|---|---|
| Relative Accuracy | +4 LSB max (AD5360) / +1 LSB max (AD5361) |
| Nominal Output Voltage Range | –10 V to +10 V |
| Supply Voltage (DVcc) | 2.5 V to 5.5 V |
| Short‑Circuit Current | 15 mA max |
The serial interface can handle clock speeds of up to 50 MHz.
The device provides a nominal output voltage range of –10 V to +10 V.
Both devices contain sixteen channels.
