The OP196/OP296/OP496 is a micropower, rail-to-rail input and output operational amplifier from Analog Devices. It features low power, wide power supply range, large input and output range, low distortion, no output phase reversal, etc. It is suitable for applications such as battery monitoring, sensor conditioning, portable power supply control, and portable instrumentation.
The OP196/OP296/OP496 family of CBCMOS operational amplifiers offers micropower operation with rail‑to‑rail input and output ranges, making them suitable for battery monitoring, sensor conditioning, and portable instrumentation. They operate from a single supply of 3 V to 12 V and are specified over an industrial temperature range of –40 °C to +125 °C.
The document includes detailed pin configurations, electrical specifications, absolute maximum ratings, an ordering guide, typical performance graphs, and mechanical dimensions for the available 8‑lead, 14‑lead, and narrow‑body SO packages.
| Gain Bandwidth Product | 350 kHz |
|---|---|
| Slew Rate | 0.3 V/µs |
The OP496 can operate from a single supply of 3 V to 12 V.
The OP496 is offered in 14‑lead plastic DIP and narrow‑body SO‑14 surface‑mount packages.
