OP07 is a ultralow input offset voltage operational amplifier launched by Analog Devices. It has ultralow input offset voltage, low input bias current, high open-loop gain and wide input voltage range. It is suitable for applications such as wireless base station control circuits, optical network control circuits, instruments and meters, sensors and controllers, thermocouples, resistor thermal detectors (RTDs), strain bridges, shunt current measurements and precision filters.
The OP07 is an ultra‑low offset voltage operational amplifier designed for precision instrumentation, sensor interfaces, and high‑gain applications. It offers a typical input offset voltage of 75 µV, low noise, and a wide supply range from 3 V to 18 V.
The device is supplied in 8‑lead PDIP and 8‑lead narrow SOIC packages, with additional CERDIP and TO‑99 options. Detailed electrical characteristics, absolute maximum ratings, and typical performance curves are provided for both the OP07E and OP07C temperature grades.
| Input Offset Voltage (typical) | 75 µV |
|---|---|
| Input Bias Current (typical) | 4.0 nA |
| Input Noise Voltage (typical, 0.1‑10 Hz) | 0.6 µV p‑p |
| Supply Voltage Range | 3 V to 18 V |
| Input Voltage Range | +13 V to +14 V |
| CMRR (typical) | 123 dB |
| Power Consumption (no‑load, 15 V) | 120 mW |
| Slew Rate (typical) | 0.3 V/µs |
| Closed‑Loop Bandwidth (typical) | 0.6 MHz |
| Available Packages | 8‑lead PDIP, 8‑lead narrow SOIC, CERDIP, TO‑99 |
The OP07 typically has an input offset voltage of 75 µV.
The device operates from 3 V up to 18 V supply voltage.
The OP07 is offered in 8‑lead PDIP, 8‑lead narrow SOIC, as well as CERDIP and TO‑99 versions.
Typical power consumption is 120 mW with a 15 V supply and no load.
