The AD8072/AD8073 is a low cost dual/triple video amplifier with good video specifications, low power consumption, high speed and easy to use
The AD8072 and AD8073 are three‑amplifier video driver ICs offered in 8‑lead (AD8072) and 14‑lead (AD8073) SOIC/DIP packages. They provide very low cost, high speed (100 MHz, –3 dB) performance and can operate from a single 5 V to 12 V supply, delivering up to 30 mA output current per amplifier.
The datasheet lists detailed electrical characteristics, absolute maximum ratings, ordering information and typical performance graphs. Key specifications include 0.1 dB gain flatness to 10 MHz, 500 V/µs slew rate, 25 ns settling time, and operation over a commercial temperature range of 0 °C to 70 °C.
| Supply Voltage Range | +2.5 V to +6 V |
|---|---|
| Operating Temperature Range | 0 °C to 70 °C |
| Input Resistance | 120 Ω |
| Quiescent Current per Amplifier | 3.5 mA (typ 5 mA) |
They operate from a single supply of +2.5 V to +6 V.
Typical quiescent current is about 5 mA per amplifier (minimum 3.5 mA).
