The AD8004 is a quad, low power, high speed amplifier designed to operate on single or dual supplies. It utilizes a current feedback architecture and features high slew rate of 3000 V/ms making the AD8004 ideal for handling fast-changing input signals.
The AD8004 is a quad, low‑power, high‑speed current‑feedback amplifier designed for single‑ or dual‑supply operation. It offers a 3000 V/µs slew rate, 250 MHz -3 dB bandwidth, and low distortion, making it suitable for video and high‑speed signal applications.
The document includes detailed electrical specifications, absolute maximum ratings, package dimensions for PDIP, SOIC, and CERDIP options, and an ordering guide covering industrial and military temperature grades.
| -3 dB Bandwidth | 250 MHz |
|---|---|
| Slew Rate | 3000 V/µs |
| Total Harmonic Distortion (5 MHz) | -78 dBc |
| Differential Gain Error | 0.04 % |
| Differential Phase Error | 0.10 ° |
| Power Supply Range | +2 V to +12 V |
| Output Current | 50 mA |
The AD8004 has a slew rate of 3000 V/µs.
It can operate from a single supply of +2 V up to +12 V.
The typical -3 dB bandwidth is 250 MHz.
