The AD8002 is a dual, low‑power, high‑speed current‑feedback amplifier designed for +5 V supplies. It offers 600 MHz -3 dB bandwidth, 1200 V/µs slew rate, and 16 ns settling time, making it suitable for professional video applications such as cameras and video switchers. The device operates from a single 3 V to 6 V supply, draws only 5.5 mA per amplifier, and can deliver over 70 mA of output current.
Available in 8‑lead plastic DIP, SOIC and uSOIC packages, the AD8002 meets industrial temperature specifications (‑40 °C to +85 °C) and includes ESD protection. Detailed specifications cover dynamic performance, noise, DC characteristics, and absolute maximum ratings.
| -3 dB Bandwidth | 600 MHz |
|---|---|
| Slew Rate | 1200 V/µs |
| Settling Time (to 0.1%) | 16 ns |
| Output Current | 70 mA |
| Supply Voltage Range | +3 V to +6 V |
| Input Offset Voltage | 2 mV |
| Total Harmonic Distortion (5 MHz) | -65 dBc |
| Operating Temperature Range | ‑40 °C to +85 °C |
The AD8002 operates from a supply voltage of +3 V to +6 V.
The device can deliver over 70 mA of output current.
The AD8002 provides a -3 dB bandwidth of 600 MHz (gain = +1).
