AD8051/AD8052/AD8054 is a low cost, high speed, single supply rail-to-rail amplifier with 110MHz/150MHz bandwidth, 50ns settling time, 45mA output current and 2.75mA/4.4mA current consumption.
The AD8051 (single), AD8052 (dual) and AD8054 (quad) are low‑cost, high‑speed voltage‑feedback amplifiers designed for video, camera, and high‑speed signal‑processing applications. They operate from a single supply (3 V to 12 V) and offer rail‑to‑rail output swings within 25 mV of either rail.
The datasheet includes detailed electrical specifications such as bandwidth, slew rate, output current capability, and temperature ranges, as well as pin‑out diagrams, typical performance curves, and an ordering guide for the various SOIC, MSOP, TSSOP and QFN packages.
| –3 dB Bandwidth (AD8054) | 150 MHz |
|---|---|
| Slew Rate | 145 V/µs |
| Maximum Output Current | 45 mA |
| Input Voltage Range | –0.2 V to +4 V |
The devices can source up to 45 mA.
The AD8054 provides a –3 dB bandwidth of 150 MHz.
