This document describes the features and parameters of the XBS024S15R-G Schottky Barrier Diode. The diode features a forward voltage of 0.33V (minimum) and a reverse current of 2μA (maximum).
The XBS024S15R-G is a 200 mA, 40 V Schottky barrier diode offered in a SOD‑523 surface‑mount package. The "-G" suffix indicates the device is halogen‑ and antimony‑free and fully RoHS compliant.
The datasheet provides key electrical parameters such as forward voltage, reverse current, and temperature limits, as well as typical performance curves and packaging information for designers and manufacturers. This manual is written in Chinese.
| Package Type | SOD-523 |
|---|---|
| Reverse Voltage (Repetitive Peak) | 40 V |
| Forward Current (Average) | 200 mA |
| Reverse Current (40 V, max) | 2 µA |
| Maximum Junction Temperature | 125 °C |
| Storage Temperature Range | -55 °C to +150 °C |
The diode is rated for a repetitive peak reverse voltage of 40 V.
It is supplied in a SOD‑523 surface‑mount package.
