MASTERLine ES 45W GU5.3 12V 24D 1CT is a MASTER bicolor coated low voltage halogen reflector with EcoBoost technology, it is the most energy-efficient bicolor lamp on the market
The MASTERLine ES is a GU5.3 MR16 lamp rated at 45 W with a 12 V supply and a 3.75 A current draw. It delivers a 24° beam angle, 5300 lm (max) luminous flux, 3000 K color temperature, and a CRI of 100 Ra8, with a rated lifetime of 5000 hours. Physical dimensions are up to 50.5 mm height and 51 mm diameter, and the lamp weighs about 42.7 g.
Packaging information includes barcodes (EAN 8711500424419, 8711500424426, 8711500410283), a 4 × 5 F carton configuration, and a net weight of 42.7 g per unit. The document also notes compliance statements from Koninklijke Philips Electronics N.V. and provides a reference to the Philips lighting website. This manual is written in Chinese.
| Rated power | 45 W |
|---|---|
| Beam angle | 24° |
| Luminous flux (max) | 5300 lm |
| Color temperature | 3000 K |
| Color rendering index | 100 Ra8 |
| Rated lifetime | 5000 hours |
| Maximum lamp base temperature | 410 °C |
| Maximum housing temperature | 410 °C |
| Height (max) | 50.5 mm |
| Diameter (max) | 51 mm |
| Weight | 42.7 g |
The lamp is rated at 45 W.
It has a 24° beam angle.
The color temperature is 3000 K.
The lamp is rated for 5000 hours of operation.
