Motorola 2700 car phone installation and operating instructions, introduces the phone and SIM card, dial and receive calls, menu summary, what to do if..., installation diagram and other content.
The guide introduces the Motorola 2700 car phone and its SIM card, explains how to make and receive calls, and provides a menu summary for users. It also includes a troubleshooting section for common issues.
Detailed installation steps are provided, including wiring color codes, required fuses, and the order of connecting the GSM handset, microphone, call‑center button, and antenna. Installation must be performed by a qualified technician. This manual is written in Chinese.
| Power Input Voltage | +12V |
|---|---|
| Ignition Input Fuse | 1A |
Installation must be done by a qualified technician: disconnect the car battery, mount the main unit, connect all wires according to the wiring table, install the GSM handset, call‑center button, microphone, antenna, insert the SIM card, then reconnect the battery.
The wiring colors are: black – ground, red – +12V (10 A fuse), purple – speaker ground, pink – speaker +, green/black – radio mute output, yellow – ignition (1 A fuse), and several unused lines.
