G3VM-62J1 is a MOSFET relay produced by OMRON. The product features a voltage resistance of 60V, a working current of 400mA, and an operating voltage of AC/DC1500Vrms. It is widely used.
The G3VM-62J1 is a MOS FET relay designed for switching very small and analog signals. It offers a dual‑channel version in the 60 V load voltage series and is suitable for semiconductor manufacturing equipment and various measuring instruments.
The manual lists key electrical parameters such as a continuous load current of 400 mA, an input‑output isolation voltage of 1500 Vrms, and a maximum load voltage of 48 V (peak AC/DC). It also provides recommended operating conditions, LED forward voltage and current values, and guidance on proper usage and wiring. This manual is written in Chinese.
| Continuous load current (peak AC/DC) | 400 mA |
|---|---|
| Input‑output isolation voltage | 1500 Vrms |
| Maximum load voltage (peak AC/DC) | 48 V |
| LED forward voltage | 1.15 V |
| LED forward current | 30 mA |
| Action LED forward current | 75 µA |
The relay can handle a continuous load current of up to 400 mA (peak AC/DC).
The input‑output isolation voltage is rated at 1500 Vrms.
The manual specifies a maximum load voltage of 48 V peak (AC/DC).
