OMRON G3VM-61LR is a SSOP-packaged MOSFET with a RON of 20pF and a VOFF of 60V, suitable for LED driver applications.
The G3VM-61LR is a MOS FET relay offered by Omron in a compact SSOP package. It features a low output capacitance (Cff≈20 pF) and a low on‑resistance, making it suitable for space‑constrained applications.
The document lists key electrical characteristics such as a maximum load voltage of 48 V (peak AC/DC), LED actuation current of 10–20 mA, continuous load current of 400 mA, and an operating temperature range of 20 °C to 70 °C. Recommended usage conditions and common precautions are also provided. This manual is written in Chinese.
| Maximum load voltage (peak AC/DC) | 48 V |
|---|---|
| LED forward current (actuation) | 10–20 mA |
| Continuous load current (peak AC/DC) | 400 mA |
| Operating temperature range | 20 °C – 70 °C |
| LED forward voltage (10 mA) | 1.15 V |
The relay can handle a peak AC/DC load voltage of up to 48 V.
An LED forward current between 10 mA and 20 mA is required for actuation.
The recommended operating temperature range is from 20 °C to 70 °C.
