This document is the user manual for ASRock 775i45GV, version 1.0, published in September 2004. It describes the features and characteristics of the product.
This manual introduces the ASRock 775i45GV Micro ATX motherboard, its package contents, key specifications, and supported AGP VGA cards. It also shows the motherboard layout and I/O connectors.
The guide walks users through installation procedures, BIOS configuration, software support, and includes an appendix with advanced BIOS options and security settings.
| Form factor | Micro ATX (9.6" x 8.5") |
|---|---|
| CPU socket | 775‑Pin LGA |
| North Bridge chipset | Intel 845GV |
| South Bridge chipset | Intel ICH4 |
| IDE ports | 2 IDE connectors, ATA100 / Ultra DMA Mode 5 |
| USB ports | 4 USB 2.0 ports (plus header for 2 more) |
| Audio | 5.1‑channel AC’97 audio |
| LAN | 10/100 Ethernet (802.3u) |
It supports Intel Pentium 4 and Celeron processors that fit the 775‑Pin LGA socket.
The motherboard provides four built‑in USB 2.0 ports and a header that can add two more USB 2.0 ports.
Enter the BIOS Security Setup menu, select "Supervisor Password", and follow the prompts to set a 1‑to‑6 character alphanumeric password.
