The ASRock Penryn1600SLI-110dB Motherboard is a motherboard from ASRock that supports the Intel Core 2 Duo E6300 processor. It has a maximum memory capacity of 8 GB of DDR2 SDRAM and supports dual-channel memory technology. It also has a 24-pin power connector.
This manual identifies the ASRock Penryn1600SLI-110dB motherboard and lists its key components, including the layout of connectors and slots. It includes reference numbers and symbols used throughout the board.
The document details the four DDRII memory slots (DDRII_1‑DDRII_4) and provides guidance for installing memory modules. Additional pages contain regulatory markings and product identification codes. This manual is written in Chinese.
| Memory Slots | 4 DDRII slots |
|---|
It has four DDRII memory slots.
The model number is Penryn1600SLI-110dB.
