ASRock P5B-DE is a high-performance gaming motherboard that supports Intel LGA775 Pentium 4 / Pentium D processors. It also supports DDR2 667/800 memory and has 6 SATAII ports and 2 IDE ports.
This guide provides step‑by‑step instructions for installing the ASRock P5B‑DE ATX motherboard. It includes hardware specifications, supported CPUs and memory, and details on the onboard connectors and BIOS features.
The document also covers safety notices, compliance information, and troubleshooting tips to help users configure the system correctly and achieve optimal performance. This manual is written in Chinese.
| CPU socket | LGA775, supports Intel Core2 Extreme, Core2 Quad, Core2 Duo, Pentium Dual‑Core, Celeron Dual‑Core |
|---|---|
| Memory slots | 4 DDR2 DIMM slots, non‑ECC, 533/667/800 MHz |
| Maximum memory | 8 GB |
| PCI Express slots | 1 x PCI‑Express x16, 1 x PCI‑Express x1 |
| SATA interface | SATA II 3.0 Gb/s |
| USB ports | 4 USB 2.0 ports (additional 4 via internal headers) |
| LAN | Gigabit Ethernet (Realtek RTL8111DL), Wake‑on‑LAN supported |
| BIOS | 4 MB AMI BIOS with Plug‑and‑Play, ACPI, and BIOS update utility |
The board uses an LGA775 socket and supports Intel Core2 Extreme, Core2 Quad, Core2 Duo, Pentium Dual‑Core, and Celeron Dual‑Core processors.
It can accommodate up to 8 GB of DDR2 memory across its four DIMM slots.
Four USB 2.0 ports are provided on the rear panel, with an additional four ports available via internal headers.
Yes, the integrated Realtek RTL8111DL Gigabit LAN controller includes Wake‑on‑LAN support.
