ASRock 775i945GZ Motherboard Quick Installation Guide

ASRock 775i945GZ motherboard installation guide.

Brand: ASRock
Category: Motherboard
Document type: Quick Start Guide
Language: English
Pages: 115
File format: PDF
File size: 1.7 MB
Published: 15 March, 2012
Updated: 30 September, 2023
Model: 775I945GZ
MD5 checksum: 309F1B7640AF7A82B73373D912640CB0
PDF: ASRock 775i945GZ Motherboard Quick Installation Guide PDF

About this manual

The ASRock 775i945GZ motherboard Quick Installation Guide provides an overview of the board’s layout, connectors, and required components. It includes a parts list, safety precautions, and step‑by‑step instructions for installing the CPU, memory, storage, and expansion cards.

The guide also outlines the motherboard’s key specifications such as chipset, memory support, audio and networking features, and provides troubleshooting tips and warranty information. Users can find additional driver and BIOS updates on the ASRock website.

What's inside

Introduction
Package Contents
Specifications
Connector Layout
Installation Precautions
CPU Installation
Memory Installation
SATA & IDE Connections
Supported PCI Express VGA Cards
BIOS Features

Specifications

Form Factor	Micro ATX (9.6 in × 8.6 in)
CPU Socket	LGA 775 (775‑Pin)
Chipset	Northbridge Intel 945GZ, Southbridge Intel ICH7
SATA Connectors	4 × SATAII 3.0 Gb/s connectors
Audio Codec	Realtek ALC888 7.1‑channel
LAN	Realtek PCI‑LAN 8101L, 10/100 Mbps

Frequently asked questions

What power connector is required for the ASRock 775i945GZ motherboard?

It uses a 4‑pin ATX 12V power connector (ATX12V1).

How many USB 2.0 ports are available on the rear panel?

The rear panel provides four Ready‑to‑Use USB 2.0 ports.

What is the maximum memory capacity supported?

The board supports up to 2 GB of DDRII memory.

How many SATA II connectors does the motherboard have?

It includes four SATA II 3.0 Gb/s connectors.

Download PDF (1.7 MB)
