This guide introduces the ASRock P67 Pro ATX motherboard, lists the package contents, and explains the board layout, I/O panel, and connector assignments. It also covers BIOS features, hardware monitoring, and special functions such as multi‑streaming audio.
Technical specifications are detailed, including supported CPUs, memory types, expansion slots, SATA and LAN interfaces, and power connectors. The guide also includes instructions for installing an operating system on drives larger than 2 TB using the UEFI BIOS.
| Form Factor | ATX (12.0‑in x 8.0‑in, 30.5 cm x 20.3 cm) |
|---|---|
| Chipset | Intel® P67 |
| LAN Interface | Realtek RTL8111E Gigabit Ethernet |
| Audio Codec | Realtek ALC892 7.1‑channel HD Audio |
| Power Connectors | 24‑pin ATX, 8‑pin 12 V |
| BIOS | 64 Mb AMI UEFI BIOS |
The board supports Windows 7/7 64‑bit, Windows Vista/ Vista 64‑bit, and Windows XP/XP 64‑bit.
The motherboard follows the ATX form factor, measuring 12.0 in × 8.0 in (30.5 cm × 20.3 cm).
