ASRock P67 Pro3 SE is a motherboard manufactured by ASRock, with features of high quality, good stability, and excellent performance.
This guide provides step‑by‑step instructions for installing the ASRock P67 Pro3 SE motherboard, including safety precautions, CPU mounting, and connector wiring. It also describes the BIOS features, firmware update tools, and optional utilities such as the ASRock Extreme Tuning Utility.
Key hardware details are listed, such as ATX dimensions, supported Intel 2nd‑generation Core processors, DDR3 memory up to 32 GB, SATA3 and USB 3.0 ports, Gigabit LAN, and audio codec. The document also outlines warranty notices and regulatory compliance information. This manual is written in Chinese.
| Form factor | ATX 12.0" x 7.5" |
|---|---|
| CPU socket | LGA1155 |
| Memory type | DDR3 (dual‑channel, non‑ECC, un‑buffered) |
| Maximum memory | 32 GB |
| SATA3 ports | 2 × 6 Gb/s |
| USB 3.0 ports | 2 × 5 Gb/s (Etron EJ168A) |
| LAN controller | Atheros AR8151 Gigabit Ethernet |
| BIOS | 64 Mb AMI BIOS (UEFI GUI) |
It uses the LGA1155 socket for Intel 2nd‑generation Core processors.
The board supports up to 32 GB of DDR3 memory in dual‑channel configuration.
There are two SATA3 ports offering 6 Gb/s transfer rates.
Atheros AR8151 provides Gigabit Ethernet connectivity.
