X79 Extreme4-M is a micro atx motherboard from ASRock. It supports Intel 39xx and 38xx series processors and supports quad-channel DDR3 memory technology. It can support up to 32GB of memory.
This Quick Installation Guide introduces the ASRock X79 Extreme4-M motherboard, lists the package contents, and presents the key specifications such as CPU support, memory capacity, and expansion slots. It also points users to the full User Manual on the support CD for more detailed information.
The guide details the motherboard layout, rear panel I/O, audio configuration, BIOS features, and unique utilities like Extreme Tuning and XFast technologies. It includes connector pin‑outs, SATA and USB specifications, and troubleshooting steps for Windows installation and system services.
| Form Factor | Micro ATX (9.6‑in x 9.6‑in, 24.4 cm x 24.4 cm) |
|---|---|
| CPU Socket | LGA 2011 (2011‑Pin) |
| Supported CPUs | Intel Core i7‑39xx & 38xx Series |
| Chipset | Intel X79 |
| Memory Slots | 4 x DDR3 DIMM slots |
| Maximum Memory | 32 GB |
| PCI Express Slots | 3 x PCIe 3.0 x16 (x16/x8/x16) |
| SATA3 Connectors | 2 x Intel 6.0 Gb/s, 1 x ASMedia 6.0 Gb/s |
| USB 3.0 Ports | 2 x Rear USB 3.0 ports |
| LAN Controller | Broadcom BCM57781 Gigabit Ethernet |
| Audio Codec | Realtek ALC898 |
It provides four DDR3 DIMM slots.
The board uses a Broadcom BCM57781 Gigabit LAN controller.
