This document describes the features and characteristics of the ASRock X58 Extreme Motherboard.
This manual explains how to install and configure the ASRock X58 Extreme motherboard. It covers safety precautions, CPU installation, BIOS setup, and connector descriptions, helping users assemble the board correctly.
The document also lists the board's technical features, including the LGA1366 CPU socket, Intel X58 chipset, up to 24 GB DDR3 memory, multiple PCI‑Express slots, SATA ports, Realtek LAN controller, and high‑fidelity audio support. This manual is written in Chinese.
| CPU socket | LGA1366 |
|---|---|
| Chipset | Intel X58 |
| Memory slots | 6 x DDR3 DIMM |
| Maximum memory | 24 GB DDR3 |
| Supported DDR3 speeds | 2000/1866/1600/1383/1066 MHz |
| PCI‑Express slots | 8 × PCI‑Express 2.0 (2 × x16, 2 × x4) |
| SATA ports | 6 × SATA 3.0 Gb/s |
| LAN controller | Realtek RTL8111DL 10/100/1000 Mb/s |
It uses an LGA1366 socket for Intel CPUs.
A Realtek RTL8111DL controller providing 10/100/1000 Mb/s Ethernet.
