ASRock X58 SuperComputer Motherboard
The X58 SuperComputer motherboard is an ATX‑form factor board featuring an Intel LGA 1366 socket, triple‑channel DDR3 support up to 24 GB, and a range of high‑speed interfaces such as PCI‑Express 2.0 x16, SATA II, USB 2.0 and Gigabit LAN. It also includes audio and video codecs, power management features, and extensive BIOS options.
This manual covers safety precautions, unpacking, CPU and heatsink installation, memory installation, connector descriptions, BIOS setup, and troubleshooting. Detailed diagrams and step‑by‑step instructions help users correctly assemble and configure the system. This manual is written in Chinese.
| Form factor | ATX 12.0" x 9.6" (30.3 cm x 24.4 cm) |
|---|---|
| CPU socket | Intel LGA 1366 |
| PCI Express slots | 4 × PCI Express 2.0 x16 (x8/x6 mode) |
| SATA ports | 6 × SATA II 3.0 Gb/s (RAID support) |
| Audio codec | Realtek ALC890 |
It uses an Intel LGA 1366 socket for compatible CPUs.
