ASRock Z68M/USB3 User Manual

This is a user manual for ASRock Z68M/USB3 motherboard

Brand: ASRock
Category: Motherboard
Document type: User Manual
Language: English
Pages: 62
File format: PDF
File size: 1 MB
Published: 14 March, 2012
Updated: 30 September, 2023
Models: Z68M, USB3
MD5 checksum: E2FCF00F1EF918BDEF6AEB3FFB0E25FB
PDF: ASRock Z68M/USB3 User Manual PDF

About this manual

This manual covers the complete hardware installation process for the ASRock Z68M/USB3 motherboard, including package contents, CPU and memory installation, and connector descriptions. It also details the UEFI BIOS configuration, RAID and SATA options, and software support utilities.

Additional sections explain Windows OS installation on large‑capacity drives, driver installation, and troubleshooting tips, with reference to the support CD and online resources.

What's inside

Package Contents
Specifications
Motherboard Layout
I/O Panel
Installation
UEFI Setup Utility
Software Support
Operating System Installation
RAID and SATA Configuration

Specifications

Form Factor	Micro ATX (9.6" x 8.6")
CPU Socket	LGA1155
Supported CPUs	2nd Generation Intel Core i7 / i5 / i3
Chipset	Intel Z68
Memory Slots	2 DDR3 DIMM slots
Maximum Memory	16 GB
SATA3 Ports	2 × 6.0 Gb/s connectors
USB 3.0 Ports	2 ports
LAN	Realtek RTL8111E Gigabit Ethernet

Frequently asked questions

How many USB 3.0 ports does the Z68M/USB3 motherboard have?

It provides two USB 3.0 ports.

What is the maximum amount of memory the motherboard supports?

The board supports up to 16 GB of DDR3 memory.

Which CPU socket is used on the Z68M/USB3 board?

It uses an LGA1155 socket.

How many SATA3 (6 Gb/s) connectors are available?

There are two SATA3 6.0 Gb/s connectors.

Download PDF (1 MB)
