Delta ASDA-B2 Series Service Manual

This is a user manual for ASDA-B2 servo driver, which mainly introduces the model, specification, appearance, wiring, parameters and fault troubleshooting of the product

Brand: Delta
Category: Industrial Robot
Document type: Service Manual
Language: Chinese
Pages: 162
File format: PDF
File size: 4.4 MB
Published: 14 March, 2012
Updated: 30 September, 2023
Model: ASDA-B2
MD5 checksum: 9CB159BBD08CF022A1C541FD5EC5CDB6
PDF: Delta ASDA-B2 Series Service Manual PDF

About this manual

This manual provides detailed information for the Delta ASDA-B2 series servo drive, including safety checks, specifications, wiring diagrams, and parameter settings. It is intended for technicians who install, commission, and maintain the drive in industrial automation applications.

The document also includes a comprehensive fault diagnosis section with step‑by‑step procedures for clearing alarms and troubleshooting common issues such as grounding problems and signal errors. This manual is written in Chinese.

What's inside

Introduction and Inspection
Specifications
Wiring Connections
Parameters and Functions
Fault Diagnosis and Troubleshooting

Specifications

Power	400W
Input Voltage	200-230V 3PH 50/60Hz
Input Current (3PH)	1.86A
Output Voltage	110V
Output Frequency	0-250Hz
Model	ASD-B2-0421-B

Frequently asked questions

How can a fault be cleared on the ASDA‑B2 servo drive?

Activate the DI ARST signal to clear the fault condition.

What connector does CN1 use?

CN1 uses a 44‑pin connector for signal and power wiring.

What power ranges are supported by the ASDA‑B2 series?

The series supports 400 W, 750 W, 1 kW‑1.5 kW, and 2 kW‑3 kW power ratings.

Download PDF (4.4 MB)
