This manual introduces the features and usage methods of the CPS1 sensorless vector control frequency converter.
This manual provides safety instructions, installation steps, wiring diagrams and operating procedures for the Delta CP2000 variable frequency drive used in HVAC applications. It includes detailed parameter tables, CANopen, PLC and BACnet communication settings, and PT100 temperature sensor configuration.
The document also contains troubleshooting guidance, specifications for input and output ratings, frequency range, and enclosure protection classes, helping technicians set up and maintain the drive safely and efficiently. This manual is written in Chinese.
| Input Voltage (Light Duty) | 3PH, 200-240V, 50/60Hz, 6.4A |
|---|---|
| Input Voltage (Normal Duty) | 3PH, 200-240V, 50/60Hz, 3.9A |
| Output Power (Light Duty) | 0-240V, 5.0A, 2.0kVA, 0.7kW, 1HP |
| Output Power (Normal Duty) | 0-240V, 3.0A, 1.2kVA, 0.7kW, 1HP |
| Frequency Range | 0‑600 Hz |
Connect the PT100 sensor’s + terminal to AFM2 and the – terminal to ACM; configure the appropriate parameter (e.g., 03‑00) for 0‑10 V operation.
The Light Duty input requires a three‑phase supply of 200‑240 V at 50/60 Hz with a current rating of 6.4 A.
