This is a user manual for S3C2443X 32-BIT RISC MICROCONTROLLERS, which mainly introduces the usage and precautions of the product
This manual introduces the Samsung S3C2443X 32‑bit RISC microcontroller, covering its features, block diagram, pin assignments, and signal descriptions. It also includes the memory map and base addresses of special registers.
Subsequent chapters detail the system controller, bus matrix, static memory controller, mobile DRAM controller, NAND flash controller, CF controller, and mechanical data such as package dimensions and index marks.
| VDD_SDRAM operating voltage | 1.8 V, 2.5 V, 3.3 V |
|---|---|
| Package type | 400‑FBGA‑1313 |
The VDD_SDRAM can operate at 1.8 V, 2.5 V, or 3.3 V.
Pin assignments are listed in Chapter 1, page 1‑6 of the manual.
The device is supplied in a 400‑FBGA‑1313 package.
