SATO DR300 barcode label printer, maximum printing range is 80mm X 178mm, printing resolution is 203dpi, printing speed is 75, 100, 125 mm/s, supports UPC-A/E, EAN-8, EAN-13, NW7, Code39, ITF2/5, Code128, UCC/EAN 128, Bookland etc. bar codes
The SATO DR300 is a barcode label printer that supports both thermal transfer and direct thermal printing methods. It offers selectable print speeds of 75, 100, or 125 mm/s and a resolution of 203 dpi, with a maximum printable area of 80 mm × 178 mm.
Physical dimensions are 302 mm × 552 mm × 294 mm and it weighs approximately 1.4 kg. The device includes a 32‑bit RISC processor, an LCD display, and a keypad for operation, and it provides RS‑232C communication along with Ready/Busy, Xon/Xoff, and Status‑3 signals. Optional accessories such as a touch‑screen unit, cutter, and label dispenser are also listed. This manual is written in Chinese.
| Printing method | Thermal transfer / Direct thermal |
|---|---|
| Maximum print width | 80 mm |
| Maximum print height | 178 mm |
| Print resolution | 203 dpi (8 pixels/mm) |
| Print speed | 75, 100, 125 mm/s (selectable) |
| Physical dimensions | 302 mm × 552 mm × 294 mm |
| Weight | 1.4 kg |
| Processor | 32‑bit RISC processor |
| Communication interface | RS‑232C, Ready/Busy, Xon/Xoff, Status‑3 |
It supports thermal transfer and direct thermal printing.
The printer can operate at 75, 100, or 125 mm/s, selectable by the user.
The device offers RS‑232C, Ready/Busy, Xon/Xoff, and Status‑3 signals.
